Load Breaking Switch

Syhf high quality load breaking switch is used to de energize or energize circuits with limited magnetism, such as transformer excitation current or line charging current. The air switch can be modified to include series interrupters (usually) to achieve higher voltage and current interruption levels. These interrupters increase the load breaking capacity of the disconnector and can be used to switch the fault current of the load or related equipment.

Advantages of load breaking switch

1. cheaper than bipolar structure

2. safer

3. transformer protection (equipped with HRC fuse for protection)

4. it is very easy to turn on and off the power supply

The load breaking switch is usually equipped with a spring mechanism to turn on and off the power supply, but it can also be selected

Vacuum circuit breaker is also available. Of course, the options of vacuum circuit breaker are more expensive. You can choose between these options

The two are completely up to the customer, and the load break switch with vacuum circuit breaker is the more reliable choice.

Load break switches with spring mechanism are usually equipped with fuse protection. Therefore, every time a fault occurs

If a fault occurs, the fuse needs to be replaced. On the other hand, if you use a load break switch with a vacuum circuit breaker, we

Just open the circuit breaker.

The load disconnect switch is also equipped with an earthing switch to help ground the possible charge

Even after the switch is turned off.
